Basic Info.
Model NO.
tape
Temperature Resistance
-70ºC~ 280ºC
Sample
as Free
Thickness
0.13mm/0.18mm/0.25mm
Width
5mm-1250mm
Release Paper
Yes/No
Adhesive Type
Pressure Sensitive
Color
Brown /Black /White
MOQ
50rolls
Delivery Time
5-10days
Feature
Heat-Resistant
Use
Masking
Material
Glass Fibre
Long-Term High Temperature Resistance
-70~260
Product Name
Teflon Tape/PTFE Tapte
Transport Package
Carton Boxes
Specification
0.13mm*10m-50m
Trademark
shenglongpan
Origin
Jiangsu
HS Code
3919109900
Production Capacity
50000000/Month
Product Description
Teflon tape is also called Teflon tape, Teflon adhesive tape or Teflon adhesive tape.
First, the glass fiber is used as the base cloth, coated with Teflon lotion and dried to
make Teflon glass fiber cloth. After secondary coating, it is a kind of high temperature
resistant adhesive tape made of silicon viscose.
Q1.Can I get the a sample?
Yes,you can get a sample for free,but you need to pay for the freight.
Q2.What is your MOQ?
100rolls for each item.
Q3.What's the size of your factory?
Around 30000 square meters
Q4.What is your payment terms?
T/T,L/C and Trade Assurance.
Q5.How many workers in your factory?
About 400-500.
Q6.What is the certificate you have?
CE ,CB, RoHS, GS
Q7.What is your main market?
South Amercia,Middle East,Europe,Southeast Asia
Q8.Hong long is the production time?
About 45-55 days after deposit received and artwork confirmed.
First, the glass fiber is used as the base cloth, coated with Teflon lotion and dried to
make Teflon glass fiber cloth. After secondary coating, it is a kind of high temperature
resistant adhesive tape made of silicon viscose.
Technical Datas of PTFE Tape
| TEFLON TAPE /PTFE Tape | ||||
| Adhesive | Pressure Sensitive | |||
| Total Thickness | 0.13mm/0.18mm | |||
| Application | Sealing machine / vacuum machine Electric abrasive protection | |||
| Total thickness | 0.13mm | 0.18mm | ||
| Adhesive Strength | 15N/25mm | 18N/25mm | ||
| Tensile strength | 17KG/25mm | 17KG/25mm | ||
| Elongation | 5% | >5% | ||
| Temperature resistance | 120° | 180° | ||
| voltage breakdown | 5KV | 5KV | ||
| Length | 10m/30m | 10m/30m | ||
| Width | 10mm/20mm/customized | 10mm/20mm/customized | ||
PTFE adhesive tape TDS
| Thickness (mm) | Max width (mm) | Adhesion (N/100mm) | Tensile strength (N/100mm) | Temp resistance (ºC) | Color |
| 0.08 | 1250 | 22 | 900 | -70~260 | Amber/black/white/customized |
| 0.13 | 1250 | 28 | 1700 | -70~260 | Amber/black/white/customized |
| 0.18 | 1250 | 48 | 2750 | -70~260 | Amber/black/white/customized |
| 0.25 | 1250 | 62 | 3650 | -70~260 | Amber/black/white/customized |
Q1.Can I get the a sample? Yes,you can get a sample for free,but you need to pay for the freight.
Q2.What is your MOQ?
100rolls for each item.
Q3.What's the size of your factory?
Around 30000 square meters
Q4.What is your payment terms?
T/T,L/C and Trade Assurance.
Q5.How many workers in your factory?
About 400-500.
Q6.What is the certificate you have?
CE ,CB, RoHS, GS
Q7.What is your main market?
South Amercia,Middle East,Europe,Southeast Asia
Q8.Hong long is the production time?
About 45-55 days after deposit received and artwork confirmed.
